SCF840-D-AS

Diesel engine driven FIRE PUMP CONTROL PANEL

Cepreven
NOVEDAD
CERTIFICADO / LISTADO
SCF840-D-AS
REQUEST A QUOTE FOR
SCF840-D-AS

Control para Bombas Diésel Contra Incendios de acuerdo a AS 2941

SCF840-D-AS son controladores diseñados para cumplir y superar los requerimientos de las normas AS 2941 y AS 3000 estando certificados y listados por  CEPREVEN; Son instrumentos de altas especificaciones donde aplican la tecnologías más avanzadas. Ofrecen prestaciones inigualables en materia de como comunicaciones, web integrada, configuraciones, versatilidad y robustez.

SCF840-D-AS Son controladores que gobiernan el proceso de arranque y parada de las Bombas Diesel Contra Incendios y las protegen mediante la acción de alarmas, tanto las conectadas como las generadas por el propio controlador; visualizan los valores e informaciones más relevantes y gestionan la comunicación con los operadores así como con los elementos de contorno tanto centro supervisado como en el  remoto.

CARACTERISTICAS PRINCIPALES: SCF840-D-AS

Control para Bombas Diésel Contra Incendios: AS 2941

  • Nº STANDARDS & TECHNICAL RULES
    1 Standard NFPA20 Ed.2019
    2 Standard NFPA70
    3 Standard IEC 61439-1 Ed. 2011 Low-voltage switchgear and controlgear assemblies
    5 EMC: EN50130-4:2011 / IEC 62599-2:2010 / EN61000-6-3:2007
    5 Electrical safety:EN61010-1:2011
  • Nº RANGE OF PRODUCTS (according to the type plate)
    1 Nominal supply voltage 110Vac – 230 Vac (Consult other voltages)
    2 Nominal frecuency 50Hz / 60Hz.

    PANEL MODELS ACCORDING TO
    BATTERY CHARGERS    		 SCF840-D-AS 12070 SCF840-D-AS 12100 SCF840-D-AS 24050 SCF840-D-AS 24100
    Nominal Voltage 12 Vdc 21Vdc 24 Vdc 24 Vdc
    Nominal Amps 7 A 100 A 5 A 10 A
    DIN Power 96,6 W 138,0 W 138,0 W 276,0 W
    Batteries capacity (C10) 200 Ah 285 Ah 142,5 Ah 285 Ah
  • Nº CONSTRUCTIVE FEATURES
    1 CE marking: EMC EN50130-4:2011 / IEC 62599-2:2010 / EN61000-6-3:2007
    2 CE marking; Electrical safety EN61010-1:2011
    3 Enclosure Ingress protection rating according to EN 60529:2018: IP65
    4 Protection against impacts degree according to EN60068-2-75:2014: IK10
    5 Fireproof degree: The fire is extinguished in <30s with dripping
    6 Display TFT full colour 3,5″ 480×272 px
    7 Cabling Free of halogens
    8 Fire resistance: RZ1 according to EN50200 (Max: 830º / 90min)
    9 Working temperatures From -5ºC to 60ºC
    10 Relative humidity (without condensation) Functional from 20 to 95%.
    11 Cooling Natural convection
    12 Maximum altitude 2000m
    13 Degree of contamination 2
    14 Overvoltage category II
    15 Environment CEM-I
    16 Anti-vibration protection EN60068-2-6:2008
  • Nº MEASURING INSTRUMENTS IN THE DISPLAY
    1 Batteries 2 Voltmeter: Battery voltage
    2 2 Ammeter: Battery charging Amp
    4 1 Battery equalization timer
    5 Engine 1 Fuel tank level meter
    6 1 Oil pressure gauge (transducer not included)
    7 1 Engine wáter  thermometer (transducer not included)
    8 1 Engine oil thermometer (transducer not included)
    9 1 Engine speed meter (sensor not included)
    10 Pump 1 Pump demand pressure meter (transducer not included)
    11 1 Pump suction pressure meter (transducer not included)
    12 1 Flow meter ( manual introduction / 4⁄20mA sender not included)
    13 System 1 Voltmenter Vac supply voltaje
    14 1 Room temperature thermometer
  • Nº PUMP & SYSTEM PROTECTION
    1 MAINS FAILURE
    2 OVER SPEED
    3 LOW OIL PRESSURE
    4 HIGH TEMPERATURE ENGINE
    5 LOW TEMPERATURE ENGINE
    6 LOW FUEL LEVEL
    7 LOW BATTERY A VOLTAGE
    8 LOW BATTERY B VOLTAGE
    9 CHARGER A FAULT
    10 CHARGER B FAULT
    11 HEATER PROTECTION TRIPPED
    12 CRANK ENGINE VOLTAGE FAIL
    13 FAILED TO START
    14 LOW DISCHARGE PRESSURE
    15 LOW RESERVOIR TANK
    16 LOW PRIMING TANK
    17 SPEED SIGNAL FAULT
    18 PRESSURE SWITCH SHORT-CIRCUIT
    19 PRESSURE SWITCH OPEN-CIRCUIT
    20 ELECTRIC MAINS FREQUENCY FAIL
    21 FAULT COMMUNICATIONS I/O
    22 FAULT COMMUNICATIONS WIFI
    23 CRANKING LEVERS FAULT
    24 LOW COOLANT TEMPERATURE
    25 DC VOLTAGE FAIL
    26 HIGH BATTERY A VOLTAGE
    27 HIGH BATTERY B VOLTAGE
    28 BATTERY A DEFECTIVE
    29 BATTERY B DEFECTIVE
    30 WATER PRESSURE SENSOR FAULT
    31 SURGE ARRESTER FAULT
    32 LOW FLOW COOLANT WATER
    33 LOW AMBIENT TEMPERATURE
    34 HIGH AMBIENT TEMPERATURE
    35 ROOM TEMPERATURE TRANSDUCER FAILURE
    36 TRIPPED HEATER PROTECTION
    37 FAULT CRANKING MOTOR VOLTAGE
    38 FAULT AUXILIARY ALTERNATOR
  • 1 USB connector type AB Firmware updatin
    2 Wifi Access to embedded website
    3 Ethernet:  Modbus / TCP-IP PC monitoring: General status of the system and pumps
    4 RS485  Modbus / RTU PC monitoring: General status of the system and pumps
    5 Voltage free relays 6 double relays 30 Vdc / 0,3 A
    6 1 double relay  250 Vac / 10 A
  • Nº LANGUAGES / OTHER FEATURES
    1 ENGLISH
    2 Monitored pressure switch lines: Short circuit / open circuit alarm
    3 Monitored connection solenoid box. Cranking levers fault alarm
    4 Pump demand  by pressure transducer analog reading of system pressure
    5 Current date and time (RTC with independent battery)
    6 1200 last events log (starts, alarms, …)
    7 12,000 latest records of system pressure variation
    8 50 pressure / Flow pump test récords
    9 Calibration of analog measurements: Pressure / Voltage / Temperature …
    10 Digital and analog inputs and outputs checking of  on the display
    11 Accumulate engine operations hours and minutes
    12 Engine cooling circuit management
    13 Engine heating resistence management
